The engine powered skid-steer loader has a small and rigid frame, outfitted together with lift arms which can connect to several industrial attachments and tools in order to carry out numerous labor saving jobs. Normally, skid-steer loaders are four-wheel drive vehicles which have the left-hand side wheels operating independent of the right-hand side wheels, even if various models are outfitted together with tracks instead. On the four-wheel models, having each side independent of each other enables the wheel speed and rotation direction of the wheels to know what direction the loader will turn.

These machines could "pirouette" or likewise known as zero-radius turning. This particular feature makes skid-steer loaders extremely valuable and maneuverable for applications that need an agile and compact loader.

The lift arms on the skid-steer loader are situated next to the driver with pivots at the back of the driver's shoulders. These features makes the skid-steer loader different compared to the conventional front loader. Because of the operator's closeness to moving booms, early skid loaders were not as safe as traditional front loaders, especially throughout the operator's exit and entry. Modern skid-steer loaders nowadays have many features to protect the driver like fully-enclosed cabs. Similar to other front loaders, the skid-steer model can push materials from one place to another, could load material into a truck or trailer and could carry material in its bucket.

There are many times where the skid-steer loader can be used instead of a large excavator on the jobsite for digging holes from within. To begin, the loader digs a ramp to be used to excavate the material out of the hole. As the excavation deepens, the machine reshapes the ramp making it longer and steeper. This is a particularly useful way for digging below a building where there is not enough overhead clearance for the boom of a large excavator. For example, this is a common situation when digging a basement below an existing structure or home.

The skid-steer loader attachments add much flexibility to the machine. Like for example, traditional buckets on the loaders can be replaced accessories powered by their hydraulics including backhoes, tree spades, sweepers, mowers, snow blades, cement mixers and pallet forks. Some other popular specialized buckets and attachments include trenchers, angle booms, dumping hoppers, wood chipper machines, grapples, tillers, stump grinders rippers, wheel saws and snow blades.

The front end 3-wheeled loader was invented during 1957, by Cyril and Louis Keller in their hometown of Rothsay, in the state of Minnesota. The Keller brothers created this machine to help mechanize the method of cleaning in turkey barns. This particular equipment was light and compact and had a rear caster wheel which enabled it to maneuver and turn around within its own length, enabling it to execute similar tasks as a conventional front-end loader.

During 1958, the Melroe brothers of Melroe Manufacturing Company in Gwinner, N.D. obtained the rights to the Keller loader. They employed the Keller brothers to continue refining their loader invention. The M-200 Melroe was the result of this partnership. This model was a self-propelled loader that was launched to the market during 1958. The M-200 Melroe featured a two independent front drive wheels, a rear caster wheel, a 12.9 HP engine and a 750 lb lift capacity. By the year 1960, they changed the caster wheel together with a rear axle and launched the very first 4 wheel skid steer loader which was referred to as the M-400.

The term "Bobcat" is used as a generic term for skid-steer loaders. The M-400 soon after became the Melroe Bobcat. The M-440 version was powered by a 15.5 HP engine and has rated operating capacity of 1100 lbs. The company continued the skid-steer development into the middle part of the nineteen sixties and launched the M600 loader.

Various makers have their own skid-steer loader model just referred to as Skidsteer within the construction trade. Hyundai, JCB, Caterpillar, Bobcat, Komatsu, Mustang, John Deere, JLG, New Holland, Gehl Company, LiuGong and ASV are a few for example, amongst some.
