Ottawa Crane Training - Bridge cranes or otherwise called overhead cranes are a type of industrial material handling crane using a line and hook apparatus that runs on a horizontal beam running along two widely separated rails. Many overhead cranes can be seen inside a long factory building and they may run along the building's two long walls, like a gantry crane.

Typically, overhead cranes have either a single beam or double beam construction. These could be built by utilizing either typical steel beams or a more complex girder style. The single bridge box girder crane is complete with the hoist and the system and is operated using a control pendant. Whenever the application requires heavier capacity systems for at least ten tons, double girder bridge cranes are more common.

With the girder box configuration, one major benefit is the lower deadweight with a stronger integrity of the overall system. One more advantage will be the hoist so as to lift the items and the bridge that spans the area covered by the crane, together with a trolley in order to move along the bridge.

Overhead cranes are more generally used within the steel business. The steel is dealt with making use of this crane at every step of the manufacturing procedure until the product is shipped from the factory. The crane is also responsible for pouring raw materials into a furnace and hot steel is then stored for cooling using an overhead crane. When the coils are finished they are loaded onto trains and trucks by overhead crane. The fabricator or stamper also relies on overhead cranes so as to handle steel in the factory.

Overhead cranes are normally used in the automobile trade for the dealing with raw material. There are smaller workstation cranes that are used to deal with lighter loads within work areas such as in CNC shops and sawmills.

In nearly all paper mills, bridge cranes could be found being utilized for regular repairs needing the removal of heavy press rolls as well as other machines. Some of the cast iron paper drying drums and other pieces of specialized equipment weigh as heavy as seventy tons. The bridge cranes are used in the preliminary construction of the paper equipment to be able to facilitate installation of these extremely heavy things.

The cost of a bridge crane can be largely offset in many circumstances with savings incurred from not renting mobile cranes when a facility is being constructed that uses lots of heavy process equipment.

The overhead Rotary crane has one of the bridge ends are attached on a fixed pivot with the other end being carried on an annular track. The bridge is able to transverse across the circular area below. Rotary Overhead cranes supply improvement more than a Jib crane by making it possible to supply a longer reach while eliminating lateral strains on the building walls.

Among the very first companies in the world to mass produce the first steam powered crane was Demag Cranes & Components Corp. Following along came Alliance Machine, who is now defunct. Alliance holds an AISE citation for one of the first cranes in the United States market. This crane was utilized in service until around 1980 and has been retired into a museum in Birmingham, Alabama.

Several innovations have come and gone since the first cranes, like for instance, the Weston load brake is currently nearly obsolete, while the wire rope hoist is still common. The wire rope hoist was first hoisted to contain components mated together to be able to form a built-up style hoist. These super industrial hoists are utilized for heavy-duty applications like steel coil handling for instance. They are also common for users who want long life and better durability from their piece of equipment. These built up hoists even provide for easier maintenance.

Today, lots of hoists are package hoists. This means they are made as one unit in a single housing which is normally designed for ten years of life. This estimate is based on an industry standard wear and tear when calculating actual life.

The Material Handling Trade in North America, there are very few governing bodies within the business. The Crane Manufacturers Association of America is represented by the Overhead Alliance that also represents HMI or also referred to as Hoist Manufacturers Institute and MMA or likewise referred to as Monorail Manufacturers Association. The members of this group are marketing representatives of the member companies and these product counsels have joined forces to create promotional materials in order to raise the awareness of the benefits to overhead lifting.
